ameriDroid 4-Port 2.5GbE Fanless Mini PC – Intel Celeron J5005 (8GB RAM / 128GB SSD, No OS)
ameriDroid 4-Port 2.5GbE Fanless Mini PC – Intel Celeron J5005 (8GB RAM / 128GB SSD, No OS)
Thank you for supporting a US-based small business!
Low stock
Couldn't load pickup availability
🎄 Sending this as a gift?
Add gift wrapping to this order for $6.95. Pricing is left out of the package.
Free standard shipping on US orders over $150
Add $150 to your cart to unlock free standard shipping. Use code FREESHIPPING at checkout.
US orders only. Excludes oversized, freight, and bulk orders. Not combinable with other discounts. Expedited shipping not included. CircuitMess items do not count toward free shipping. The FREESHIPPING code must be entered at checkout.
Description ▼
ameriDroid 4-Port 2.5GbE Fanless Mini PC – Intel Celeron J5005 (8GB RAM / 128GB SSD, No OS)
A compact, completely silent mini PC with four Intel I225 2.5 GbE LAN ports. Built around the low-power quad-core Intel Celeron J5005, it's a great fit for firewalls, VPN routers, network servers, home labs, and other always-on jobs where low noise and low power draw matter. We've configured it with 8 GB of DDR4 RAM and a 128 GB SATA SSD, so all you need to add is the operating system of your choice.
Key Features
- Intel Celeron J5005 (Gemini Lake) quad-core, 4 threads, 1.5 GHz base / up to 2.8 GHz turbo, 4 MB cache
- Only 10 W TDP – low power draw, ideal for 24/7 operation
- 4 × Intel I225 2.5 GbE RJ45 LAN ports – perfect for firewalls, routers, VLANs, and multi-network setups
- 8 GB DDR4 RAM installed (1× SO-DIMM slot)
- 128 GB SATA SSD installed
- Fanless all-aluminum chassis – no fan noise at all
- HDMI 1.4 and VGA video outputs, 1× USB 3.0, 1× USB 2.0
- Auto power-on after power loss, Wake-on-LAN, PXE boot, and RTC support
- Ships with a metal bracket so it can stand vertically
Why choose this mini PC
- Completely silent and low power, so it can sit in a living space, closet, or rack without a sound
- Four real Intel 2.5 GbE ports in a small footprint – a popular choice for pfSense and other firewall/router builds
- Ready to go with RAM and SSD already installed – just add your OS
- Room to grow: spare storage slots and a mini PCIe port for a Wi-Fi module
- Compact 173 × 127 × 39 mm chassis fits almost anywhere
What's in the box
- M3-J5005 L4 Mini PC with 8 GB DDR4 RAM and 128 GB SATA SSD installed
- Power adapter + power cord
- Metal stand bracket
- Screws bag
Please note
- No operating system is included. You'll need to install your own (see supported operating systems below).
- No Wi-Fi module is included. The unit has a full-size mini PCIe slot if you'd like to add one yourself.
Specifications
| Type | Description |
|---|---|
| Model | M3-J5005 L4 |
| Processor | Intel Celeron J5005 (Gemini Lake, 14 nm) 4 cores / 4 threads, 1.5 GHz base, up to 2.8 GHz turbo 4 MB cache, 10 W TDP |
| Graphics | Intel UHD Graphics 605 |
| Memory | 8 GB DDR4 installed 1 × SO-DIMM slot |
| Storage | 128 GB SATA SSD installed Interfaces: 1 × mSATA 3.0 slot, 1 × SATA 3.0 port for 2.5" HDD/SSD |
| Networking | 4 × Intel I225 2.5 GbE RJ45 LAN ports Wi-Fi: 1 × mini PCIe (full-size) slot, module not included |
| Video Output | 1 × HDMI 1.4 1 × VGA |
| I/O Ports | 1 × USB 3.0 1 × USB 2.0 1 × Power on/off switch 1 × Reset (RST) button 2 × Status LEDs 2 × Kensington lock holes |
| Power | Adapter input: 100–240 V AC, 50–60 Hz DC input: 12 V to 19 V (12 V / 5 A recommended) |
| BIOS | AMI BIOS, ACPI supported Auto power-on, Wake-on-LAN, PXE, RTC |
| Cooling | Fanless (passive) |
| Size | Chassis: 173 × 127 × 39 mm |
| Weight | Net 0.8 kg |
| Chassis Material | Black aluminum alloy |
| Operating Environment | Operating temperature: 0 to 70 °C Storage temperature: -20 to 80 °C Humidity: 0–90% (non-condensing) |
| OS Support | Windows 10 / Linux / pfSense (no OS included) |
