Door / Window Sensor 7 Pro

The Aeotec Door Window Sensor 7 Pro is a window sensor that detects exactly whether your window is open, closed or tilted, for which there must be a tilt angle of at least 5°. It can be easily retrofitted to the window. The sensor is simply attached to the sash frame. In addition, a small magnet must be installed near the sensor on the window frame.

With the Aeotec Door Window Sensor 7 Pro you can integrate other binary sensors such as NTC contacts, micro switches or flood sensors into your Z-Wave system. With the potential-free input of the Aeotec Door Window Sensor 7 Pro, it is also possible for the sensor to integrate other sensors into your Z-Wave system, for example. For this purpose, the binary sensors are connected to the potential-free input of the sensor. In addition to sensors, buttons can also be connected at this point, which, for example, start a scene in the Z-Wave center.

Should your Aeotec Door Window Sensor 7 Pro fail you, the heart of it - the circuit board - can be easily replaced without removing the sensor. This means you can stick the device to the window frame and just replace the circuit board.

FEATURES

• Aeotec's smallest, full-featured open/close sensor; 40% smaller than Door / Window Sensor Gen5.
• 2 sensors built-in: open/close sensor and tilt sensor.
• Additionally can be used connected 3rd party electronics to your Z-Wave system using the sensor's universal binary input / dry contact sensor.
• Features SmartStart and S2 security technologies.
• Powered by one 1/2 AA (ER14250), Door / Window Sensor 7 uses 66% less battery power to communicate via Z-Wave Plus than older models did. Offers up to 3-year battery life depending on gateway it connects with.
• Uses Z-Wave Plus with Gen7 and 700 series wireless technologies.
