Radxa Cubie A7Z
The Radxa Cubie A7Z is an ultra-compact Allwinner A733 single-board computer in a 65 × 30 mm form factor. This version has 2GB LPDDR4 RAM and the 40-pin GPIO header. It combines a hybrid octa-core CPU, 3 TOPS NPU, Wi-Fi 6, Bluetooth 5.4, Micro HDMI, dual USB-C, and PCIe expansion for edge AI, embedded, and robotics projects.
KEY FEATURES
- Allwinner A733 — 2× Cortex-A76 + 6× Cortex-A55, up to 2.0 GHz
- 2GB LPDDR4 RAM
- 40-pin GPIO header
- 3 TOPS NPU @ INT8
- Wi-Fi 6 + Bluetooth 5.4
- Micro HDMI up to 4K@60Hz
- USB-C 3.1 with DisplayPort Alt Mode
- PCIe 3.0 x1 FPC expansion
- Ultra-compact 65 × 30 mm board
SPECIFICATIONS
| Category | Details |
|---|---|
| Processor | SoC: Allwinner A733 CPU: 2× Cortex-A76 + 6× Cortex-A55, up to 2.0 GHz GPU: Imagination BXM-4-64 MC1 (OpenGL ES 3.2, Vulkan 1.3, OpenCL 3.0) NPU: 3 TOPS @ INT8 |
| Memory | 2GB LPDDR4 / LPDDR4x |
| Storage | microSD card slot |
| Networking | Onboard Wi-Fi 6 (802.11 a/b/g/n/ac/ax) Bluetooth 5.4 with BLE External antenna connector |
| Video | 1 × Micro HDMI (up to 4K@60Hz) USB-C 3.1 DisplayPort Alt Mode |
| Camera | 1 × 4-lane MIPI CSI |
| USB | 1 × USB-C 2.0 OTG (power + data) 1 × USB-C 3.1 OTG (data + DP Alt Mode) |
| Expansion | 40-pin GPIO (UART, I2C, SPI, PWM) PCIe Gen3 x1 FPC 3-pin fan connector |
| Power | USB-C 5V 5V via GPIO pins 2 and 4 5V / 1A adapter recommended |
| Software | Debian Linux Android 13 |
| Physical | 65 × 30 mm Operating temperature: 0°C to 50°C |
What's Included:
- 1 × Radxa Cubie A7Z (2GB RAM, with GPIO)
NOTES
- This board has 2GB RAM and the 40-pin GPIO header
- A microSD card is needed for the operating system
- A 5V USB-C power supply is required
- Excellent tiny option for edge AI, embedded control, and compact Linux / Android projects
