Reolink E1 Zoom
Reolink E1 Zoom
Low stock
Couldn't load pickup availability
Description ▼
Smart 2K+ Wired PoE Video Doorbell with Chime
Upgraded to 4K, the E1 Zoom now captures stunning 3840×2160 footage—170% more pixels than before. With 3× optical zoom, it brings distant details into sharp focus without losing clarity. The enhanced F1.6 aperture lets in more light than F2.0 lenses, delivering brighter images even in low light.
FEATURES
- 4K Ultra HD & 3× Optical Zoom
- Person/Pet/Crying Detection
- Auto Tracking with Pan & Tilt
- Dual-Band Wi-Fi 6 & Bluetooth Setup
SETUP GUIDE
SPECIFICATIONS
| Video & Audio | |
| Image Sensor | 1/2.8" CMOS Sensors |
|---|---|
| Resolution | 3840×2160 (8 Megapixels) @20fps |
| Lens | f=2.8-8mm, Max: F1.6 |
| Zoom | 3× optical zoom |
| Infrared Night Vision | Up to 12 meters (40ft); LED: 10pcs/850nm (Auto-switching with IR-cut filter) |
| Frame Rate | Main Stream: 2fps - 20fps (default: 20fps) Sub Stream: 4fps - 15fps (default: 10fps) |
| Code Rate | Main Stream: 2048Kbps - 5120Kbps (default: 4096Kbps) Sub Stream: 64Kbps - 512Kbps (default: 256Kbps) |
| Audio | Two-way audio |
| Power Requirements | |
| DC Power | DC 5.0V⎓2A |
| Interface | |
| Power Port | DC power port |
| Reset Button | YES |
| Ethernet Port | One 10M/100Mbps; RJ45 |
| SD Card Slot | Supports Max. 512GB microSD card |
| Audio In/Out | Built-in microphone and speaker |
| Wi-Fi | |
| Wireless Standard | IEEE 802.11 ax/ac/a/b/g/n |
| Operating Frequency | 2.4GHz/5GHz |
| Wireless Security | WPA/WPA2/WPA3 |
| Pan & Tilt | |
| PT Angle (Max.) | Pan: 355°, Tilt: 50° |
| Preset Points | Supports 1 guard position & up to 64 preset positions |
| Power-off Memory Function | YES |
| Auto Tracking | YES (Only Pan) |
| Software | |
| Browsers Supported | Edge, Chrome, Firefox, Safari |
| OS Supported | PC: Windows, Mac OS; Smartphone: iOS, Android |
| Protocols & Standards | HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, ONVIF, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P |
| User Access | Max. 20 users (1 admin & 19 user); Max. 12 simultaneous streams (2 main & 10 sub streams) |
| Other Features | |
| Smart Alarm | Motion detection/person detection/pet detection/crying detection |
| Record Mode | Motion-triggered recording (default); scheduled recording; 24/7 recording |
| Time Lapse | YES |
| Smart Home Compatibility | Alexa, Google Assistant |
| Privacy Mode | YES |
| Working Environment | |
| Operating Temperature | -10°C to +55°C (14°F to 131°F) |
| Operating Humidity | 20%–85% |
| Mechanical | |
| Dimensions | Φ84x118mm |
| Weight | 275g |
| Warranty | |
| Limited Warranty | 2-year limited warranty. For support, visit https://support.reolink.com/hc/en-us/ |
