The KickPi K7 is a high-performance single board computer powered by the Rockchip RK3576 octa-core processor with four Cortex-A72 and four Cortex-A53 cores, a Mali-G52 MC3 GPU and a 6 TOPS NPU. With dual Gigabit Ethernet, three USB 3.0 ports, HDMI up to 4K@120Hz, a USB Type-C port with DisplayPort, M.2 storage and 4G/5G module support, it is suited to IoT gateways, NVR storage, industrial control, AI edge computing and in-vehicle control systems. Android 14 is pre-installed on the onboard eMMC, with Debian, Ubuntu and Armbian also supported.
KEY FEATURES
- Rockchip RK3576 Octa-Core: Quad Cortex-A72 + quad Cortex-A53 for strong multitasking performance
- 6 TOPS NPU: Built-in RKNN NPU for AI inference and computer vision at the edge
- Dual Gigabit Ethernet: Two 1000M ports, plus dual-band Wi-Fi and Bluetooth (VS6621SR80)
- 4G/5G Ready: Supports 4G (Quectel EC20/EC200) and 5G (Quectel RG200U) mobile network modules
- High-Resolution Displays: HDMI up to 4K@120Hz, MIPI DSI up to 2560×1600@60Hz and DisplayPort over USB Type-C
- Triple Camera Input: Three 4-lane MIPI CSI camera interfaces
- Android & Linux: Android 14, Debian 12, Ubuntu 24.04 and Armbian
BUILT FOR EDGE AI AND INDUSTRIAL USE
The RK3576 pairs eight CPU cores with a 6 TOPS NPU, and the K7 adds three USB 3.0 host ports, M.2 storage, an IR receiver, RTC, speaker, microphone and earphone support, and a 40-pin expansion header with UART, SPI, PWM, ADC, I2C, I3C and CAN for industrial and AIoT projects.
SPECIFICATIONS
| Category | Details |
|---|---|
| Model | KickPi K7 |
| SoC | Rockchip RK3576 |
| CPU | Quad-core Cortex-A72 + quad-core Cortex-A53 |
| GPU | Mali-G52 MC3 |
| NPU | RKNN 6 TOPS |
| Memory (RAM) | 4GB or 8GB (depending on option selected) |
| Storage (eMMC) | 32GB or 64GB onboard eMMC (depending on option selected) TF card slot M.2 slot |
| Video Output | HDMI ×1, up to 4K@120Hz MIPI DSI ×1, up to 2560×1600@60Hz DisplayPort 1.4 via USB Type-C |
| Camera | MIPI CSI 4-lane ×3 |
| Audio | Speaker, earphone and microphone support |
| Networking | Gigabit (1000M) Ethernet ×2 Dual-band Wi-Fi + Bluetooth (VS6621SR80) 4G (EC20/EC200) and 5G (RG200U) module support |
| USB | USB 3.0 Host ×3 USB Type-C ×1 (USB 3.1 OTG / USB debug / DP 1.4) |
| Expansion Header | 40-pin: UART ×5, SPI ×1, PWM ×8, ADC ×1, I2C ×3, I3C ×1, GPIO ×22, PDM ×1, CAN ×1 |
| Other | IR receiver, RTC (HYM8563), debug serial port, cooling fan header Power LED and running LED Recovery, Reset, Maskrom and Power buttons |
| Power | DC 12V (1.5A or higher) |
| Operating Systems | Android 14, Debian 12, Ubuntu 24.04, Armbian |
| PCB Size | 141 × 80 mm |
What's Included:
- 1 × KickPi K7 single board computer (RAM/eMMC per selected option)
NOTES
- Variants differ only in RAM and eMMC capacity: 4GB RAM / 32GB eMMC or 8GB RAM / 64GB eMMC.
- Android 14 AOSP is pre-installed on the onboard eMMC. To use another OS, KickPi recommends a TF (microSD) card of 16GB or larger for booting or flashing.
- Power: requires a 12V DC power supply rated at 1.5A or higher. A power supply is not listed as included.
- Some generic HDMI displays may flicker; KickPi recommends trying another display or lowering the HDMI resolution/refresh rate.
- Default Linux logins per KickPi: Debian 12 linaro/linaro, Ubuntu 24.04 kickpi/kickpi, Armbian kickpi/kickpi.
- Install or remove MIPI displays only with the board powered off.
- OS images, documentation and support are provided by KickPi at kickpi.com and doc.kickpi.com.
