MangoPi MQ-Pro

In Stock

$35.95

MangoPi MQ-Pro (MPi-MQ1PH) is an Allwinner D1 RISC-V SBC that offers an alternative to Raspberry Pi Zero W with the same form factor, and most of the same features including WiFi/BT and DSI.

SPECIFICATIONS

  • SoC – Allwinner D1 C906 RISC-V processor @ up to 1GHz with G2D 2D graphics accelerator

  • System Memory - 1GB DDR3L

  • Storage – MicroSD card socket

  • Display – mini HDMI 1.4 port up to 1080p60 or 4Kp30, 20-pin MIPI DSI, CTP, LVDS FPC connector

  • Camera I/F – 24-pin DVP/RGMII connector

  • Audio – Audio out pads

  • Networking

  • 2.4Ghz 802.11b/g/n WiFi 4 and Bluetooth 4.2 via RTL8723DS module + u.FL antenna connector

  • Ethernet via expansion board connected to 24-pin DVP/RGMII connector

  • USB – 1x USB OTG Type-C port, 1x USB host Type-C port

  • Expansion – 40-pins Raspberry Pi compatible GPIO header

  • Power Supply – 5V via USB Type-C port or 40-pins GPIO header

  • Dimensions – 65 x 30 mm

OPERATING SYSTEMS

  • Visit MangoPi MQ-Pro page here to download images and more information.

NOTES

  • The board can not handle all workload possible on the Raspberry Pi Zero W as the Allwinner D1 SoC lacks a 3D GPU. The board should work best for headless applications, or for HDMI applications with a simple 2D user interface.

  • Heatsink not included
