SwitchBot Roller Shade

$199.95 USD

Sale Sold out

Shipping calculated at checkout.

Size Small (22.8" - 31.5") Medium (31.5" - 43.3") Large (L: 43.3" - 55.1") Extra Large (55.1" - 72.8")

Out of Stock! If you see a Pre-order badge and/or an Add to Cart button, you can place a pre-order now!

Quantity

Description ▼

FEATURES

Perfect fit for all windows
Easily adjust the retractable curtain box for a snug fit, even with measurement errors. Covers window widths from 22.8" to 72.8".
Replaceable roller blind fabrics
Switch fabrics effortlessly to match your style or functionality needs. Keep your current curtains by upgrading only the motor unit.
Smart and remote control options
Control blinds via app, voice, remote, or wired controller. Supports group control for up to 8 blinds per group, perfect for large spaces.
Battery-free convenience with solar power
Install the optional solar panel for unlimited power (USB-C Solar Battery). Even without it, a full battery charge lasts up to 8 months.
Ultra-quiet operation
The DC motor ensures whisper-quiet performance, with noise levels as low as 30dB in silent mode.
Matter and smart home integration (SwitchBot Hub 2 required)
Compatible with Alexa, Google Assistant, Siri Shortcuts, and more. Supports percentage control for precise adjustments, offering personalized settings for your smart home needs. Bluetooth integration for Home Assistant expected to realease during April.

Choosing the Right Size for Your Roller Shade:

How to install

NOTES

Product Size	S: 82 × 72 × 580–800 mm (3.2 × 2.8 × 22.8–31.5 in.) M: 82 × 72 × 800–1100 mm (3.2 × 2.8 × 31.5–43.3 in.) L: 82 × 72 × 1100–1400 mm (3.2 × 2.8 × 43.3–51.1 in.) XL: 82 × 72 × 1400–1850 mm (3.2 × 2.8 × 55.1–72.8 in.)
Fabric Size	S: 756 × 2200 mm (29.8 × 86.6 in.) M: 1056 × 2200 mm (41.5 × 86.6 in.) L: 1356 × 2200 mm (53.4 × 86.6 in.) XL: 1806 × 2200 mm (71.2 × 86.6 in.)
Mounting Bracket Size	75 × 40 × 30 mm (2.953 × 1.575 × 1.181 in.)
Applicable Environments	1. Inside window frame: Frame depth must be at least 7 cm. For a fully recessed blind, a depth of 9 cm is required. The roller blind should be 0.5 cm narrower than the window to allow for installation. Note: This will result in small gaps on both sides. For complete blackout, consider using the alternative installation method below. 2. Outside window frame: The roller blind should be 10 cm wider than the window to ensure full coverage. 3. The product size shows all the dimensions of the product while the curtain fabric size only shows the dimensions of the curtain fabric. If mounted inside the window frame, the roller blind should be 0.5 cm narrower than the window to allow for installation which will result in small gaps on both sides. For complete blackout, consider mounting outside of the window frame.
Package Weight	S: 3.6 kg M: 4.9 kg L: 5.5 kg XL: 6 kg
Net Weight (Without Fabric)	S: 1.16 kg M: 1.4 kg L: 1.64 kg XL: 2.0 kg
Fabric Weight	S: 1.20 kg M: 1.44 kg L: 1.95 kg XL: 2.55 kg
Package Size	S: 847.99 × 121.3 × 141.8 mm (33.385 × 4.776 × 5.583 in.) M: 1147.99 × 121.3 × 141.8 mm (45.196 × 4.776 × 5.583 in.) L: 1447.99 × 121.3 × 141.8 mm (57.008 × 4.776 × 5.583 in.) XL: 1897.9 × 121.3 × 141.8 mm (74.720 × 4.776 × 5.583 in.)
Color	Headrail: Silvery Fabric: White/Grey
Material	Aluminum alloys, ABS
Coating	Anodizing, sandblasting
Operating Temperature	0°C~45°C
Operating Humidity	10~95% RH
Battery Capacity	2 built-in 18650 lithium batteries 2600 mAh
Input	5V DC ⎓ 1A
Battery Life	8 months (Note: The battery life is tested under the following conditions: an ambient temperature of 25 ºC, a height of 1.85 m, a product weight of 4 kg, and rolling up and down once per day. Actual battery life may vary depending on usage.)
BLE	≥5.0（LongRange）
Connectivity Range	Max. 80 m without obstacles
Third-party Services	Alexa, Google Assistant, Siri Shorcuts, IFTTT, SmartThings, Matter (SwitchBot Hub required), Home Assistant via SwitchBot Hub and Bluetooth integration will be released during April
Operating Mode	Standard Mode QuietDrift Mode
Operating Noise	Standard Mode: ≤35dB QuietDrift Mode: ≤ 30dB
Operating Speed	Standard Mode: ≤30s QuietDrift Mode: ≤200s (Refers to the time for one session of opening or closing; height: 2m)
