ThinkNode M2 Mini Meshtastic LoRa Radio – ESP32-S3 with 1.3" OLED Display (No Case)
ThinkNode M2 Mini Meshtastic LoRa Radio – ESP32-S3 with 1.3" OLED Display (No Case)
Thank you for supporting a US-based small business!
In stock
Couldn't load pickup availability
Free standard shipping on US orders over $150
Add $150 to your cart to unlock free standard shipping. Use code FREESHIPPING at checkout.
US orders only. Excludes oversized, freight, and bulk orders. Not combinable with other discounts. Expedited shipping not included. CircuitMess items do not count toward free shipping. The FREESHIPPING code must be entered at checkout.
Description ▼
Ultra-compact off-grid Meshtastic communication in your pocket – ThinkNode M2! This tiny LoRa transceiver combines the powerful ESP32-S3 with an SX1262 LoRa chip and a crisp 1.3-inch OLED display for real-time status and messaging. Pre-loaded with Meshtastic firmware, it delivers encrypted text, location sharing, and mesh networking without cell service, internet, or satellite. Perfect for hiking, camping, emergency preparedness, or everyday carry as a miniature digital walkie-talkie.
The ThinkNode M2 is designed for Meshtastic, offering:
- Long-Range LoRa Communication: SX1262 LoRa transceiver supports EU868 / US915 frequencies for reliable encrypted messaging and hop-by-hop relay across your private mesh network.
- Real-Time OLED Display: 1.3-inch 128×64 OLED screen shows signal strength, messages, node status, and battery level at a glance—no need to pull out your phone.
- Powerful ESP32-S3 Core: Dual-core Xtensa LX7 processor up to 240 MHz with Wi-Fi and Bluetooth 5.0 for fast performance, app configuration, and future expansion.
- Built-in 1000mAh Battery: Rechargeable lithium battery provides long standby time for extended outdoor adventures or emergency use.
- Easy Meshtastic Integration: Pre-installed Meshtastic firmware pairs seamlessly with the free Meshtastic™ app for messaging, location sharing, channel monitoring, and custom settings via Bluetooth.
- Compact Bare-Board Design: Extremely small and lightweight (no case included) — ideal for pocket carry, embedding into projects, or mounting in tight spaces.
- Multiple Applications: Use as a portable Meshtastic client/node for two-way communication, a simple tracker, or integrate into custom IoT and mesh projects.
Specifications
| Feature | Specification |
|---|---|
| Main Processor | ESP32-S3 (Xtensa 32-bit LX7 dual-core, up to 240 MHz) |
| Memory | 512 KB SRAM, 8 MB PSRAM, 4 MB Flash, 384 KB ROM |
| LoRa Chip | SX1262 |
| LoRa Frequency | EU868 / US915 |
| Wireless | Wi-Fi 802.11 b/g/n, Bluetooth 5.0 + BLE |
| Display | 1.3" OLED, 128×64 resolution, SSH1106 driver |
| Battery | 1000 mAh rechargeable lithium |
| Antenna | External LoRa antenna via IPEX connector |
| Interfaces | USB-C, IPEX antenna, battery connector |
| Buttons | Power, Function, Reset, BOOT |
| Indicators | Power and charging LEDs |
| Firmware | Pre-installed Meshtastic firmware |
| Size (Without Case) | 51.5 × 37 × 9.5 mm |
| Net Weight (Without Case) | 30 g |
| Operating Temperature | -10°C to +50°C |
Package List:
- 1x ThinkNode M2 Mini Meshtastic LoRa Radio (Without Case)
- 1x USB-A to USB-C Charging Cable
- 1x User Manual
