FriendlyELEC NanoPi R5C
The NanoPi R5C is a compact dual-2.5GbE router / SBC based on the Rockchip RK3568B2. This unit has 4GB LPDDR4X RAM, 64GB eMMC, and includes the case. Dual 2.5G Ethernet, HDMI, USB 3.0, and FriendlyWrt / Linux support make it a strong small gateway, NAS node, or always-on homelab board.
KEY FEATURES
- Rockchip RK3568B2 quad-core Cortex-A55, up to 2.0 GHz
- 4GB LPDDR4X RAM
- 64GB eMMC
- Dual 2.5GbE Ethernet (RTL8125BG)
- HDMI up to 4K
- 2 × USB 3.0
- M.2 E-key for Wi-Fi / Bluetooth
- Includes case
- FriendlyWrt, Debian, Ubuntu, OpenMediaVault, and Proxmox support
SPECIFICATIONS
| Category | Details |
|---|---|
| CPU | Model: Rockchip RK3568B2 Number of Cores: Quad-core ARM Cortex-A55 Frequency: 4 × Cortex-A55 up to 2.0 GHz |
| GPU | Mali-G52 1-Core-2EE OpenGL ES 1.1 / 2.0 / 3.2, Vulkan 1.0 / 1.1, OpenCL 2.0 |
| VPU | 4K@60fps H.265 / H.264 / VP9 decode 1080p@60fps H.264 / H.265 encode |
| NPU | 0.8 TOPS |
| Memory | 4GB LPDDR4X |
| Storage | 64GB eMMC 1 × microSD slot (UHS-I) |
| Connectivity | 2 × 2.5GbE Ethernet (RTL8125BG) 1 × M.2 E-Key (PCIe 2.1 x1 + USB 2.0) for Wi-Fi / Bluetooth module |
| Video Output | 1 × HDMI (HDMI 1.4 / 2.0, up to 4096×2304@60Hz) |
| USB | 2 × USB 3.0 Type-A (USB 3.2 Gen1) 1 × USB-C power only (5V) |
| Debug | UART, 3-pin 2.54mm header, 3.3V, 1500000 bps |
| LED | 1 × SYS LED (Red) 1 × WAN LED (Green) 1 × LAN1 LED (Green) 1 × LAN2 LED (Green) |
| Button | 1 × MASK button for eMMC update 1 × User button |
| Others | RTC battery: 2-Pin 1.27/1.25mm connector for HYM8563TS Working temperature: 0℃ to 70℃ |
| Power | DC 5V/2A (non-PD) |
| OS Support | Alpine Linux 3.23 Android 14 Tablet / Android 14 TV Buildroot - Weston (Wayland) Debian 12 Desktop LXQT / Debian 13 Core FriendlyCore 20.04 Qt5 FriendlyWrt 25.12 OpenMediaVault 8.0.6 Proxmox VE 8.2.7 Ubuntu 24.04 Core / Ubuntu 24.04 Desktop LXQT |
| Kernel | Linux-6.1-LTS U-boot-2017.09 *Firmware is continuously updated; refer to the actual version provided by the wiki |
| PCB | 8-layer |
| Dimensions | 58 × 58 × 1.6 mm (board) 62.5 × 62.5 × 29 mm (with case) |
| Weight | 38 g (board) 149 g (with case) |
What's Included:
- 1 × NanoPi R5C (4GB LPDDR4X / 64GB eMMC)
- 1 × Case
NOTES
- This unit has 4GB RAM, 64GB eMMC, and includes the case
- A 5V / 2A USB-C power supply is required (non-PD)
- Wi-Fi / Bluetooth requires an M.2 E-key module (Antennas not included)
- Excellent compact option for FriendlyWrt / OpenWrt, dual-2.5G routing, NAS, and small Linux servers
